Jet 350020 JMD-18PFN Power Downfeed 2HP Mill Drill NIB

This Jet 350020 JMD-18PFN 2 HP 230V Mill Drill Combo is Brand New!

Tool Zone Special: Free Mill Dril Stand 350045

Jet JMD-18PFN Mill Drill Features:
• One-piece cast iron column for added support
• Belt cover - quick slide latch allows faster belt adjustment to change spindle speeds
• Base - taper allows for easier clean-up
• Larger hand wheel knobs
• UL listed motor
• Extra large worktable
• Heavy-duty tapered roller bearings support the spindle, resulting in greater tolerance and more accurate drilling depth
• New positive quick-stop knob and easy-to-read internal depth gauge
• Extra large worktable
• 360 degree head swivel
• Heavy-duty power downfeed with manual fine feed
• Three power down feeds

Jet JMD-18PFN Mill Drill Ships With The Following Standard Equipment:
• Worklamp
• Adjustable carbide facemill
• Drill Press angle vise
• 1/2” drill chuck, chuck arbor
• Draw Bar

Jet JMD-18PFN Mill Drill Specifications:
• Model Number: JMD-18PFN
• Drilling Capacity (in.): 1-1/4
• Face Mill Capacity (in.): 3
• End Mill Capacity (in.): 3/4
• Swing (in.): 15-7/8
• Max Distance Spindle to Table (in.): 26
• Spindle Taper: R-8
• Spindle Travel Manual (in.): 5
• Spindle Travel Auto (in.): 4-1/4
• Quill Diameter (in.): 3
• Column Diameter (in.): 4-1/2
• Number of Spindle Speeds: 12
• Range of Spindle Speeds (RPM): 150 - 3,000
• Max. Table Travel (in.): 24
• Cross Travel (in.): 7
• Working Surface of Table (in.): 9-1/2 x 31-3/4
• T-slots, Number and Size (in.): 4 and 5/8
• T-slot Centers (in.): 1-13/16
• Base Dimensions (in.): 15-3/4 x 23-3/4
• Motor (UL Listed): 2HP, 1Ph, 230V Only
• Overall Dimensions (in./L x W x H): 42-1/2 x 39-3/4 x 51-1/2
• Net Weight (lbs.): 700



Shipping Costs Shown Are For The 48 States Only! AK & HI Please email for quote!
