McCauley 6000 12" massive 300 watt Speakers
Way High End!
Model 6334 - Close to the JBL E120
This auction/sale is for One Speaker.
TOTAL: We have (2) for sale.
McCauley is so Cool!
Code: 6334 Price: $376.00 ea. Shipping Weight: 20.00 pounds
The 6334 12" is a high performance basket assembly designed to reproduce midrange source material when paired with a McCauley 6510CX or 6520CX HF coaxial compression driver.
Professional Guitar or Pa
12 in. woofer 300 watts RMS
Great Stuff Guys!
These are 8 ohms & Made in the USA
| Performance |
|
| Freq. Response (-3dB) |
55Hz - 4kHz |
| Recommended Enclosure Volume |
23ft³ 651.29L |
| Power Handling (RMS) |
|
| Full Range |
300W |
| Max Peak SPL |
|
| Full Range |
129.771dB |
| Max Continuous SPL |
|
| Full Range |
123.771dB |
| Sensitivity |
|
| Full Range |
99dB |
| Theile Small |
|
| Free Air Resonance (Fs) |
60 |
| 4Ù DC Coil Resistance (Re/Dcr) |
6Ù |
| Electrical Losses (Qes) |
0.32 |
| Mechanical Losses (Qms) |
9.65 |
| Total Quality Factor (Qts) |
0.31 |
| Equivalent Volume of Air (Vas) |
1.87ft³ 52.95L |
| Effective Piston Area (Sd) |
82.6in.² 532.9cm² |
| Excursion -- Max BL (Xmax) |
0.13in. 3.3mm |
| Volumn Displacement (Vd) |
10.9in.³ 0.18L |
| Inductance of V.C. (Le) |
1.1mH |
| BL Factor |
19.4Tm |
| Effective Moving Mass |
0.053kg 1.87oz. |
| Nominal Efficiency |
0.034% |
| Flux Density |
13500 gauss | |
| Physical |
|
| Bolt Circle Diameter |
11.45in. 290.83mm |
| Effective Piston Diameter |
10.25in. 260.35mm |
| Front Mount Baffle Cutout Diameter |
10.91in. 277.11mm |
| Driver Diameter |
12in. 304.8mm |
| Dimensions |
|
| Product Dimensions |
12.125in. x 4.6in. x 12.125in. 307.97mm x 116.84mm x 307.97mm |
| Net Weight |
3.08lbs. 1.4kg. |
| Shipping Dimensions |
16in. x 7in. x 16in. 406.4mm x 177.8mm x 406.4mm |
| Shipping Weight |
4lbs. 1.81kg. |
| Design Properties |
|
| Characteristics |
Cone Driver |
| Magnet |
|
| Assembly Weight |
17lbs. 7.71kg. |
| Gap Depth |
0.295in. 7.49mm |
| Voice Coil |
|
| Diameter |
4in. 101.6mm |
| Winding Depth |
0.5in. 12.7mm | |
McCauley Sound
