New 3M Foldable SMA GPS Antenna For Garmin Navman Holux

SKU:ANT-GPS005

Click to get larger picture

Description:

100% Brand New Generic (non-OEM) High Quality 3M SMA GPS Antenna with 90 degree foldable Male connector
Magnetic mount GPS antenna,which has a magnetic base and water resistant allows you to fix this to the outside paint work of the car without any screw or glue
It does not need any extra power, which uses power from antenna socket on the GPS device
his GPS antenna is a high performance GPS patch antenna with the state-of-the-art low noise amplifiers while only consuming 10 mA of power.
It delivers one of the highest signal gain of ALL the GPS antennas we have tested!
Permanemt magnets will interfere with pilots, boaters and hikers with the magnetic compass readings.
100% Waterproof

Specification:

LNA Gain: 28.5dB
Noise Figure: 1.5dB
Center Frequency: 1575.42MHz ±1.023MHz
V.S.W.R: 1.5:1
Band Width: ±8MHz
Impendence: 50ohm
Peak Gain pl: >3dBic Based on 7x7cm ground plane
Gain Coverage: >-4dBic at -90°<0<+90°(over 75% Volume)
Polarization: RHCP
Working Temp: -40℃～+85℃
Vibration: Sine sweep 1g(0-p)10～50～10Hz each axis
Humidity: Humidity 95%～100%RH
DC Voltage: 2.7 ～ 3.6V
DC Current: 3.0V @ 9mA
Weight: <90 gram
Size: 35*33*13mm
Cable: 3 meters
Connector: SMA (with PIN inside)
Mounting: Magnetic base
Color: Black

Compatibility:

Alpine GPS Receivers:	Blackbird PMD-B100 Portable Navigation System
Navman GPS Receivers:	Navman Tracker 5100, 5500, 5600 (comparable to Navman 1330 GPS Antenna)
Trimble GPS Receivers:	TNL1000 Aviation GPS
Navman	Tracker 5100
	Tracker 5100i
	Tracker 5110
	Tracker 5110i
	Tracker 5380
	Tracker 5380i
	Tracker 5430
	Tracker 5430i
	Tracker 5500
	Tracker 5500i
	Tracker 5505
	Tracker 5505i
	Tracker 5600
	Tracker 5605
GlobalSat	AT-65-SMA
	TT-300
	G5010U
	G5040
Holux	GM 82 Engine Board
Rikaline	Active Antenna SMA A-10302-SA
	Active Antenna SMA A-10305-SA
	GPS-300 Black Box
	Standard Horizon CP 150 (Passive 3 foot Only)
	Standard Horizon CP 160
	Standard Horizon CP 170
	Synergy Systems AR-10K GPS Antenna SMA 10001699
	Synergy Systems AR-10S GPS SMA Antenna 1001411
	Synergy Systems AR-10S GPS SMA Antenna 1001414
	CP 170 (Passive 3 foot Only)
	CP 160 (Passive 3 foot Only)
fTech	GPS Antenna SMA FGPANE1A2
fTech	GPS Antenna SMA FGPANE1A5
Trimble	TNL 1000 Panelmount GPS (5.2 V DC)
	CrossCheck CDPD
	CrossCheck GPRS 1900
	CrossCheck GSM 900
Tele Type Satellite Tracker v2.0	/

Package content:

3M GPS SMA Antenna with 90 degree foldable connector x 1pc
