Product Type
Memory Type — CompactFlash Type I/II, Microdrive, xD-Picture Card (Dual-Slot)
Sensor size — 17.3 mm (H) x 13.0 mm (V)
Lens mount — Four Thirds Mount
Effective Pixels number — 10 million pixels
Image Pickup Unit
Type — Live MOS Sensor
Filter array — Primary color filter (RGB)
IR cut filter — Hybrid type
Dust reduction — Supersonic Wave Filter (dust reduction system for image sensor)
Recording
Recording format — DCF, DPOF compatible/Exif, PRINT Image Matching III
File format — RAW (12-bit), JPEG, RAW+JPEG
Recording image size — [RAW] 3648 x 2736 pixels • [JPEG] 3648 x 2736 pixels - 640 x 480 pixels
Live View
Live View — Live MOS Sensor for still picture shooting is used, 100% field of view, Exposure adjustment preview, White balance adjustment preview, Gradation setting preview, Face detection preview, Perfect Shot preview, Grid line displayable, 7x/10x magnification possible, MF/S-AF, AF frame display, AF point display, Shooting information, Histogram, IS Activating mode.
AF — High-speed imager AF, Phase difference detection AF
Image stabilizer
System — Built in (Imager shift image stabilizer)
Mode — 3 modes (2-dimensional activation (Horizontal + Vertical), 1-dimensional activation (Vertical), 1-dimensional activation (Horizontal)
Effective compensation range — up to 4EV steps maximum
General
Dimensions — 5.4 in. (W) x 3.6 in.(H) x 2.7 in. D / 136 mm (W) x 91.5 mm (H) x 68 mm (D) (excluding protrusions)
Weight — 16.8 oz. / 475 g (body only)
|
Exposure Control
Metering system — TTL open-aperture metering system
• Digital ESP metering (49-point multipattern metering); • Center-weighted average metering; • Spot metering (approx. 2% of the viewfinder screen); • Spot with Highlight control; • Spot with Shadow control
Metering range — EV 1 - 20 (Digital ESP metering, Center-weighted average metering, Spot metering)
(At normal temperature, 50mm f2, ISO 100)
Exposure mode — • Auto; • P: Program AE (Program shift can be performed); • A: Aperture priority AE; • S: Shutter priority AE; • M: Manual; • Scene program AE; • Scene select AE
Scene program AE — Portrait, Landscape, Macro, Sport, Night + Portrait
Scene select AE — Portrait, Landscape, Landscape + Portrait, Night Scene, Night + Portrait, Children, Sport, High Key, Low Key, Digital Image Stabilization, Macro, Nature Macro, Candle, Sunset, Fireworks, Documents, Panorama (requires Olympus xD-Picture Card media), Beach & Snow, Underwater Wide, Underwater Macro.
ISO sensitivity — AUTO (ISO 100 - 1600) / Manual (ISO 100 - 1600), 1 EV steps
Exposure compensation — ±5 EV in 1/3, 1/2, 1 EV steps selectable
AE lock — Locked by first position of Shutter button / AEL button (customizable)
Exposure bracketing — 3 frames in 0.3, 0.7, 1EV steps selectable
Viewfinder
Field of view — Approx. 95%
Viewfinder magnification — Approx.0.92x (-1m-1, 50mm lens, infinity)
Preview — Can be checked (when Fn button is set in preview mode), selectable from the optical viewfinder or rear-mounted LCD monitor
Eye point — Approx. 14 mm (-1m-1)
Focusing screen — Fixed (Neo Lumi-Micro Mat screen)
|
