| Dimensions
LxWxH 26.5x13.5x38
Shoe Size 11x13
Operating Weight 137 lbs.
Shipping Weight 146 lbs.
Shipping size LxWxH 28.5x15.5x38
Operating System:
Wacker WM80 gasoline engine
Displacement in3 4.9
Maximum power 4hp.
Maximum operating speed 4400rpm
Fuel to oil ratio 25-50.1
Fuel consumption qt/gal .1.0
Fuel tank capacity qt 3.2
Specifications:
Compaction Depth 23in.
Stroke 2.6in.
Force/blow 3025lbs.
Percussion Rate blows per min. up to 700
Travel speed ft/min up to 57
Compaction area ft/hr 3135 |
Features and Benefits
Large enclosed air filtration system.
Large capacity corrosion-proof fuel tank with self-cleaning in-tank
filter.
Single lever for throttle, engine, fuel, and ignition controls engine
speed, and combines fuel and engine shut-off.
Exclusive noise reducing cover.
Wacker 2 cycle engine meets EPA air emissions standards
Tinker-proof diaphragm carburetor.
Lightweight and Well-balanced machine allows greater operator control.
Long shoe stroke gives excellent compaction.
Fully sealed oil lubricated ramming system.
Shock mounted guide handle with padded grip.
Ductile iron shoe extends shoe life.
|
