Original nVidia Graphics MXM Video Card
	The card compatible MXM slot in Laptop, some of laptop need update bios.

Brand:   nVidia

Model: Geforce 8600M GT / G84-600-A2 (G84M)

Memory Size: 512MB (8pcs DDR2 32 x 16)

Bios: Acer / nVidia

Type: MXM-II (73mm x 78mm)

Condition: New & Unused

Parts: MXM Card, 6x HeatSink Sticker, 4x Screws & Driver Disc

Warranty: Doa 30days

(If removed sticker or sign, no warranty)

Payment: Paypal or T/T (Bank Transfer)

Remark:

1. The MXM card tested in laptop & 3D mark befor sent.

2. Some of Laptop need updated bios & compatible it.

3. If the MXM card driver conflict with some device driver in laptop,

    the operate system maybe need re-install.

4. Pls paste the heat sticker as below photo before install the card.

 NVIDIA GeForce 8600M GT

NVIDIA GeForce 8600M GT is the DirectX 10 capable successor of the GeForce Go 7600 GT for laptops. Depending on the used graphic memory and the clock speed,  the performance is between the 7600 GT and 7900 GS video card. Therefore, games like Company of Heroes, Supreme Commander, or F.E.A.R can be played fluently with high details in a resolution of 1024 or similar. Still, the shader power is not sufficient to display DirectX 10 effects of games like Crysis fluently (Crysis will only run well in low details).  Gamers, who every time expect supreme frame rates, should get at least a 8800M card.

The 8600M series is one of the first-laptop-GPUs, which support DirectX 10 and accelerate the H.264-decoding of HD-movies.

The particularity of this video card are the "Unified Shader". Pixel- and vertex-shaders do not exist any more but 32 of the so called stream processors do the graphic work (which up to now pixel- and vertex shaders did).

The memory clock speed depends on the used memory: 400 MHz for GDDR2 memory and 700 Mhz for GDDR3 (which is noticeable faster).

The integrated PureVideo engine is one of the advantages of the 8600M GT. It supports (HD) encoding of H.264, VC-1, MPEG2, and WMV9 video content. Compared to the slower 8600M GS (and 8400M series) the 8600M GT supports a few more video features (see comparison chart).

Manufacturer	NVIDIA
Series	GeForce 8M
Codename	G84M
Pipelines	32 - unified
Core Speed *	475 MHz
Shader Speed *	950 MHz
Memory Speed *	700 MHz
Memory Bus Width	128 Bit
Memory Type	GDDR3, GDDR2
Max. Amount of Memory	512 MB
Shared Memory	no
DirectX	DirectX 10, Shader 4.0
Current Consumption	20 Watt
Transistors	289 Million
technology	80 nm
Features	Shader clock frequence 950 MHz, PureVideo technology (H.264, VC-1, MPEG2, WMV9 decoding acceleration), MPEG2, WMV9 decoding acceleration), HDCP-capable, PowerMizer 7.0 power management (dynamic switching between performance and energy economizing), HDR (High Dynamic-Range Lighting), designed for Windows Vista, 16x full screen AA, 16x AF independent of angles, 128-Bit HDR illumination with AA, Dual-Link DVI-D exits for resolutions of TFT up to 2560x1600, PCI-E 16x, OpenGL 2.1, Gigathread technology
Notebook Size	medium sized
Date of Announcement	09.06.2007
Information	Speichertakt (Vorgaben): DDR2 - 400 MHz DDR3 - 700 MHz
