Specs
Signal System HDV: 1080/60i, 1080/24p, DVCAM/DV: 480/60i (NTSC)
Image Device 1/4" 3CMOS ClearVid Sensor
Lens Carl Zeiss Vario-Sonnar T* Zoom Lens, 20x (Optical),
Horizontal Resolution 1080 Lines
Minimum Illumination 4 Lux f1.6 at 18dB
Built-in Filters 1/4 ND, 1/16 ND
LCD Monitor Clear Photo LCD Plus, 3.5", 16:9 Aspect Ratio
Viewfinder 0.44", 252,000 Pixels, 16:9 Aspect Ratio
Scan Matching Yes
Memory Card Slot MemoryStick Duo Media
Shutter Speed Range 60i: 1/4, 1/8, 1/15, 1/30, 1/60, 1/90, 1/100, 1/125, 1/180, 1/250, 1/350, 1/500, 1/725, 1/1000, 1/1500, 1/2000, 1/3000, 1/4000, 1/6000, 1/10000, , 24p: 1/3, 1/6, 1/12, 1/24, 1/40, 1/48, 1/50, 1/60, 1/96, 1/100, 1/120, 1/144, 1/192, 1/200, 1/288, 1/400, 1/576, 1/1200, 1/2400, 1/4800, 1/10000 sec
Gain Selection 0, 3, 6, 9, 12, 15, 18dB
|
VTR Tape Format DVCAM Small Cassette, HDV Record and Play, DVCAM Record and Play, DV Record and Play
Tape Speed HDV: 18.8 mm/s, DVCAM: 28.2 mm/s, DV SP Mode: 18.8 mm/s
Maximum Recording Time HDV: 63 min (with PHDVM-63DM Cassette), DVCAM: 41 min (with PHDVM-63DM Cassette), DV: 63 min (with PHDVM-63DM Cassette)
Audio
Audio Signal Format HDV, MPEG1 Audio Layer II, DVCAM/DV, 16-bit/48kHz 2 Channel Mode, 12-bit/32kHz 4 Channel Mode
General Input and Output Connectors Composite Video: RCA (x1 Output, A/V Out 10-pin Connector Jack), Component Video (x1 Output), HDV/DV I/O: i.LINK FireWire Interface, Audio: XLR 3-Pin (x2 Input), Headphones: Stereo Mini Jack, LANC: Stereo Mini-mini (2.5mm) Jack, USB: Mini-B Connector, HDMI Output: HDMI Connector
Power Requirements 7.2VDC
Power Consumption HDV: 6.8W, DVCAM/DV: 6.6W
Operating Temperature 32-104°F (0-40°C)
Weight 3.4 lb (1.5kg)
|
