Imaging Resolution 12.3 Megapixel
Sensor 17.3 x 13.0 mm (Four-Thirds) High speed Live MOS Sensor
Bit Depth 36-bit RGB (RAW)
File Formats RAW (lossless compressed), JPEG (Super fine, Fine, Normal, Basic), RAW+JPEG
File Size 0.1MB (640 x 480 - JPEG/Basic) - 13.9MB (4032 x 3024 - RAW)
Color Spaces sRGB, Adobe RGB , (Vivid, Natural, Portrait, Muted, Monotone, Custom)
Image Stabilization Imager Shift Image Stabilizer
Crop Factor 2.0x
Optics Lens Not Applicable
Zoom Not Applicable
Lens Mount Four Thirds Mount
Focus Type Normal: TTL phase-difference detection AF, Contrast detection system AF, Manual,
Live View: High speed imager AF, Phase-difference detection AF, Manual
Focus Range Depends on lens used
Accessory Lens/Filter Mount Depends on lens used
Shooting Controls Sensitivity Auto ISO (200 - 3200) customizable,
Manual ISO (100 - 3200 in 1/3 or 1 EV steps)
Shutter Speeds 60 - 1/4000 second,
Bulb (up to 30 minutes in 1/3, 1/2, or 1EV steps selectable)
Metering TTL open-aperture metering system ,
(Digital ESP with 49-points, Center weighted average, Spot), Highlight / shadow bases are available
Exposure Modes Auto, P: Program AE (Program shift can be performed) , A: Aperture priority AE, S: Shutter priority AE, M: Manual , Scene program AE, Scene select AE
White Balance Hybrid detection system with High speed Live MOS sensor and dedicated external sensor,
Preset White balance (Lamp, Fluorescent 1, Fluorescent 2, Fluorescent 3, Daylight, Flash, Cloudy, Shade), White balance compensation (±7 steps in each A-B/G-M axis), CWB - Kelvin setting (2000K - 14000K), One-touch white balance, White balance bracketing (3 frames in 2, 4, 6 steps selectable in each A-B/G-M axis)
Mirror Lock-Up Not Applicable
Burst Capability Sequential Shooting H: 4 fps,
Sequential Shooting L: 1 to 3 fps , Up to 5 Frames in RAW
Self Timer 12 seconds or 2 seconds
Remote Control RM-UC1 Remote Cable (optional)
|
Flash Built-in Flash Yes - Retractable flash (Auto, Red-eye reduction, Red-eye reduction slow sync., Slow sync at 1st curtain, Slow sync at 2nd curtain, Fill-in, Manual (1/4, 1/16, 1/64), Off.)
Effective Flash Range GN=17 at ISO200, (GN=12 at ISO 100.m)
External Flash Connection Hot Shoe,
Wireless Flash Control (with FL-50R & FL-36R)
Dedicated Flash System TTL Auto, Auto,
(with FL-50R, FL-36R, FL-50, FL-36 & FL-20)
Max Sync Speed 1/180 second
Memory Built-in Memory No
Memory Card Type Compact Flash (Type I & II)/Microdrive ,
xD-Picture Card
Still Images per GB 10,000 images (640x480/Basic) - 72 images (4032x3024/RAW)
Viewfinder/Display Viewfinder Type Eye-level single-lens reflex viewfinder
Viewfinder Coverage 95%
Display 2.7" Swivel HyperCrystal TFT color LCD (230,000 pixels)
Connectivity/System Requirements Connectivity USB 2.0 High Speed for storage and camera control ,
Dedicated multi-connector (Video: NTSC/PAL selectable, Optional Remote cable RM-UC1)
System & Software Requirements Windows XP& Vista,
Macintosh OS X (10.3 or later)
Environmental Operating/Storage Temperature 32-104 °F (0-40 °C)/-4 - 140 °F (-20 - 60 °C)
Weatherproofing Weather resistant
Power Battery Type BLS-1 Rechargeable Lithium-ion Battery
Physical Dimensions 5.1" x 3.7" x 2.4" (130 x 94x 60 mm) Body Only
Weight 16.6 oz. (475 g) Body Only
|
